RC Circuit

Here, we build an RC circuit model with variable numbers of components to show scaling of compile and runtimes of MTK vs OpenModelica and Dymola.

Setup Model Code

using ModelingToolkit, OrdinaryDiffEq, BenchmarkTools,
      ModelingToolkitStandardLibrary, OMJulia, CairoMakie
using OrdinaryDiffEqRosenbrock
using ModelingToolkitStandardLibrary.Blocks
using ModelingToolkitStandardLibrary.Electrical
# ModelingToolkit
const t = Blocks.t

function build_system(n)
    systems = @named begin
        sine = Sine(frequency = 10)
        source = Voltage()
        resistors[1:n] = Resistor()
        capacitors[1:n] = Capacitor()
        ground = Ground()
    end
    systems = reduce(vcat, systems)
    eqs = [connect(sine.output, source.V)
           connect(source.p, resistors[1].p)
           [connect(resistors[i].n, resistors[i + 1].p, capacitors[i].p)
            for i in 1:(n - 1)]
           connect(resistors[end].n, capacitors[end].p)
           [connect(capacitors[i].n, source.n) for i in 1:n]
           connect(source.n, ground.g)]
    @named sys = ODESystem(eqs, t; systems)
    u0 = [capacitors[i].v => float(i) for i in 1:n];
    ps = [[resistors[i].R => 1 / i for i in 1:n];
          [capacitors[i].C => 1 / i^2 for i in 1:n]]
    return sys, u0, ps
end

function compile_run_problem(sys, u0, ps; duref = nothing)
    tspan = (0.0, 10.0)
    t0 = time()
    prob = ODEProblem(sys, merge(Dict(u0), Dict(ps)), tspan; sparse = true)
    (; f, u0, p) = prob
    ff = f.f
    du = similar(u0)
    ff(du, u0, p, 0.0)
    t_fode = time() - t0
    duref === nothing || @assert duref ≈ du
    t_run = @belapsed $ff($du, $u0, $p, 0.0)
    t_solve = @elapsed sol = solve(prob, Rodas5(autodiff = AutoFiniteDiff()))
    @assert SciMLBase.successful_retcode(sol)
    (t_fode, t_run, t_solve), du
end

function run_and_time_julia!(ss_times, times, total_times, max_sizes, i, n)
    sys, u0, ps = build_system(n);
    if n <= max_sizes[1]
        ss_times[i] = @elapsed sys_mtk = mtkcompile(sys)
        times[i], _ = compile_run_problem(sys_mtk, u0, ps)
        t_fode, t_run, t_solve = times[i]
        total_times[i, 1] = ss_times[i] + t_fode + t_solve
    end
end
run_and_time_julia! (generic function with 1 method)
N = [5, 10, 20, 40, 60, 80, 160, 320, 480, 640, 800, 1000, 2000,
    3000, 4000, 5000, 6000, 7000, 8000, 9000, 10000, 20000];

# max size we test per method
max_sizes = [4_000, 9000];

# NaN-initialize so Makie will ignore incomplete
ss_times = fill(NaN, length(N));
times = fill((NaN, NaN, NaN), length(N));
# columns: MTK, OpenModelica, Dymola
total_times = fill(NaN, length(N), 3);

Julia Timings

@time run_and_time_julia!(ss_times, times, total_times, max_sizes, 1, 4); # precompile
for (i, n) in enumerate(N)
    @time run_and_time_julia!(ss_times, times, total_times, max_sizes, i, n)
end
146.259260 seconds (159.62 M allocations: 8.331 GiB, 2.61% gc time, 99.67%
compilation time: 41% of which was recompilation)
  2.244823 seconds (2.04 M allocations: 117.109 MiB, 82.01% compilation tim
e)
  1.705885 seconds (1.52 M allocations: 86.799 MiB, 6.59% gc time, 74.91% c
ompilation time)
  2.101985 seconds (1.83 M allocations: 102.772 MiB, 67.14% compilation tim
e: 17% of which was recompilation)
  2.638787 seconds (2.33 M allocations: 124.900 MiB, 3.74% gc time, 49.77%
compilation time)
  3.021953 seconds (2.86 M allocations: 151.221 MiB, 42.07% compilation tim
e)
  3.179322 seconds (3.39 M allocations: 178.471 MiB, 2.30% gc time, 41.84%
compilation time)
  3.812848 seconds (5.80 M allocations: 300.068 MiB, 2.24% gc time, 43.12%
compilation time)
  6.714507 seconds (10.69 M allocations: 577.099 MiB, 8.30% gc time, 35.41%
 compilation time)
  9.575064 seconds (16.02 M allocations: 914.004 MiB, 6.65% gc time, 35.27%
 compilation time)
 13.817375 seconds (21.84 M allocations: 1.273 GiB, 5.91% gc time, 31.05% c
ompilation time)
 20.129964 seconds (27.85 M allocations: 1.694 GiB, 5.66% gc time, 28.65% c
ompilation time)
 27.732686 seconds (36.49 M allocations: 2.331 GiB, 4.94% gc time, 26.45% c
ompilation time)
 73.611030 seconds (85.03 M allocations: 6.640 GiB, 6.30% gc time, 23.63% c
ompilation time)
146.652901 seconds (153.51 M allocations: 13.480 GiB, 5.66% gc time, 20.24%
 compilation time)
223.844708 seconds (239.46 M allocations: 21.979 GiB, 5.96% gc time, 20.23%
 compilation time)
  0.463587 seconds (2.42 M allocations: 130.509 MiB)
  0.551857 seconds (2.90 M allocations: 162.224 MiB)
  1.010606 seconds (3.40 M allocations: 195.862 MiB, 23.80% gc time)
  1.157541 seconds (3.87 M allocations: 263.057 MiB)
  1.224175 seconds (4.38 M allocations: 230.193 MiB, 25.74% gc time)
  0.935296 seconds (4.83 M allocations: 259.967 MiB)
  2.373103 seconds (9.76 M allocations: 521.321 MiB, 17.05% gc time)

OpenModelica Timings

# OMJ
omod = OMJulia.OMCSession();
OMJulia.sendExpression(omod, "getVersion()")
OMJulia.sendExpression(omod, "installPackage(Modelica)")
const modelicafile = joinpath(@__DIR__, "RC_Circuit.mo")

function time_open_modelica(n::Int)
    try
        local res
        totaltime = @elapsed res = begin
            @sync ModelicaSystem(omod, modelicafile, "RC_Circuit.Test.RC_Circuit_MTK_test_$n")
            sendExpression(omod, "simulate(RC_Circuit.Test.RC_Circuit_MTK_test_$n)")
        end
        msgs = string(get(res, "messages", ""))
        startswith(msgs, "LOG_SUCCESS") || error("omc messages: $msgs")
        return totaltime
    catch e
        @warn "OpenModelica timing failed" n exception = (e,)
        try
            OMJulia.quit(omod)
        catch
        end
        global omod = OMJulia.OMCSession()
        OMJulia.sendExpression(omod, "getVersion()")
        OMJulia.sendExpression(omod, "installPackage(Modelica)")
        return NaN
    end
end

function run_and_time_om!(total_times, max_sizes, i, n)
    if n <= max_sizes[2]
        total_times[i, 2] = time_open_modelica(n)
    end
end

for (i, n) in enumerate(N)
    @time run_and_time_om!(total_times, max_sizes, i, n)
end

OMJulia.quit(omod)
3.995983 seconds (794.62 k allocations: 40.117 MiB, 22.40% compilation ti
me)
  2.500448 seconds (4.15 k allocations: 277.500 KiB)
  3.144874 seconds (7.77 k allocations: 517.672 KiB)
  4.761399 seconds (15.35 k allocations: 1016.453 KiB)
  6.301581 seconds (20.70 k allocations: 1.325 MiB)
  7.878132 seconds (27.34 k allocations: 1.773 MiB)
 14.484362 seconds (54.91 k allocations: 3.458 MiB)
 28.026293 seconds (112.49 k allocations: 7.285 MiB)
 43.661124 seconds (165.61 k allocations: 10.412 MiB, 1.02% gc time)
 56.988123 seconds (213.26 k allocations: 13.822 MiB)
 73.112881 seconds (288.23 k allocations: 18.236 MiB)
 92.728636 seconds (332.78 k allocations: 21.866 MiB)
198.996195 seconds (686.63 k allocations: 43.192 MiB)
313.669027 seconds (1.08 M allocations: 70.840 MiB)
435.709727 seconds (1.33 M allocations: 83.225 MiB)
573.056063 seconds (1.66 M allocations: 108.456 MiB)
778.813293 seconds (1.99 M allocations: 124.820 MiB, 0.06% gc time)
990.698651 seconds (2.32 M allocations: 154.606 MiB)
1302.723597 seconds (2.74 M allocations: 172.666 MiB, 0.03% gc time)
482.070012 seconds (77.28 k allocations: 4.990 MiB, 0.03% compilation time)
  0.000001 seconds
  0.000000 seconds

Dymola Timings

Dymola requires a license server and thus cannot be hosted. This was run locally for the following times:

translation_and_total_times = [5 2.428 2.458
                               10 2.727 2.757
                               20 1.764 1.797
                               40 1.849 1.885
                               60 1.953 1.995
                               80 2.041 2.089
                               160 2.422 2.485
                               320 3.157 3.258
                               480 3.943 4.092
                               640 4.718 4.912
                               800 5.531 5.773
                               1000 6.526 6.826
                               2000 11.467 12.056
                               3000 16.8 17.831
                               4000 22.355 24.043
                               5000 27.768 30.083
                               6000 33.561 36.758
                               7000 39.197 43.154
                               8000 45.194 52.153
                               9000 50.689 57.187
                               10000 NaN NaN
                               20000 NaN NaN]

total_times[:, 3] = translation_and_total_times[:, 3]
22-element Vector{Float64}:
   2.458
   2.757
   1.797
   1.885
   1.995
   2.089
   2.485
   3.258
   4.092
   4.912
   ⋮
  17.831
  24.043
  30.083
  36.758
  43.154
  52.153
  57.187
 NaN
 NaN

Results

f = Figure(size = (800, 800));
let ax = Axis(f[1, 1]; yscale = log10, xscale = log10, title = "Structural Simplify Time")
    lines!(N, ss_times)
end
for (i, timecat) in enumerate(("ODEProblem + f!", "Run", "Solve"))
    title = timecat * " Time"
    ax = Axis(f[i + 1, 1]; yscale = log10, xscale = log10, title)
    lines!(N, getindex.(times, i))
end
f

f2 = Figure(size = (800, 400));
title = "Total Time: RC Circuit Benchmark"
ax = Axis(f2[1, 1]; yscale = log10, xscale = log10, title)
names = ["MTK", "OpenModelica", "Dymola"]
_lines = map(enumerate(names)) do (j, label)
    ts = @view(total_times[:, j])
    lines!(N, ts)
end
Legend(f2[1, 2], _lines, names)
f2

Appendix

Appendix

These benchmarks are a part of the SciMLBenchmarks.jl repository, found at: https://github.com/SciML/SciMLBenchmarks.jl. For more information on high-performance scientific machine learning, check out the SciML Open Source Software Organization https://sciml.ai.

To locally run this benchmark, do the following commands:

using SciMLBenchmarks
SciMLBenchmarks.weave_file("benchmarks/ModelingToolkit","RCCircuit.jmd")
